Equipment

Below are some of HDM's wide variety of CNC equipment and software packages.

Milling

Mazak 500a-5a  5-Axis Milling Center

Mazak 500a-5a 5-Axis Milling Center

5-Axis Trunnion Rotary Table

20" Platter Diameter

14,000 Max RPM

(2 ea) Mori Seiki CNC Milling Center (NV5000)

(2 ea) Mori Seiki CNC Milling Center (NV5000)

40" x 20" x 25" (xyz) travel

Tsudakoma 4th axis Rotary table

14,000 Max RPM Spindle

Haas VF-4 Milling Center

Haas VF-4 Milling Center

50" x 20" x 25" (xyz) table travel

4th-Axis Rotary

15000 RPM Spindle

Haas VF-3SS Super Speed Milling Center

Haas VF-3SS Super Speed Milling Center

40" x 20" x 25" (xyz) table travel

5th-axis Trunnion

15,000 RPM Spindle

Okuma CNC Milling Center Model MX-45VA

Okuma CNC Milling Center Model MX-45VA

18" x 30" x 24" table travel

OSP700M Control

(2 ea) Mori Seiki CNC Milling Center (MV40)

(2 ea) Mori Seiki CNC Milling Center (MV40)

32" x 20" x 20" (xyz) table travel

Yasnac MX-M3 CNC Control

Turning

Haas DS 30 SSY Dual-Spindle Lathe with Live Tooling

Haas DS 30 SSY Dual-Spindle Lathe with Live Tooling

10" Chuck (spindle 1) 6" Chuck (spindle 2)

30 HP (spindle 1) 20 HP (spindle 2)

24 Station Turret

Mori Seiki NL 2500 SY Dual-Spindle Lathe with Live Tooling

Mori Seiki NL 2500 SY Dual-Spindle Lathe with Live Tooling

10" Chuck (spindle 1)  6" Chuck (spindle 2)

35 HP (spindle 1)  15 HP (spindle 2)

12-station turret head

Mazak Quick Turn Turning Center

Mazak Quick Turn Turning Center

10" chuck with 3 1/2" thru hole, 42" between centers

30 horsepower motor

Mazatrol T-Plus control with EIA option

Yang CNC Turning Center Model ML55-A

Yang CNC Turning Center Model ML55-A

18" chuck with 4.6" thru hole 38.5 between centers
12 station turret, programmable tail stock, Fanuc OT Control

Mori Seiki CNC Turning Center

Mori Seiki CNC Turning Center

15 horsepower SL-20 with 1 5/8" x 12' hydrostatic LNS bar feed and automatic parts catcher
Fanuc 10 T A CNC Control

Mori Seiki CNC Turning Center

Mori Seiki CNC Turning Center

SL 3 H with 3" thru hole and 24" between centers
10" chuck
Fanuc 10 T F with conversational control
Collet chuck system with collet capabilities of 1/4" to
1 3/4"

Swiss Turn

(3 ea) Tornos Bechler 20.0 mm Deco 20

(3 ea) Tornos Bechler 20.0 mm Deco 20

.787 inch Capacity Swiss-Turning Center

Tornos Bechler 25.4 mm Deco 20

Tornos Bechler 25.4 mm Deco 20

1 inch Capacity Swiss-Turning Center

Other

Nikon LKV 15.7.6 CMM

Nikon LKV 15.7.6 CMM

1500mm x 700mm x 600mm travel
Ceramic Bridge
Renishaw PH20 Probe Head

Mitsubishi FA1-S Wire EDM Machine

Mitsubishi FA1-S Wire EDM Machine

Daito GA260W NC saw with bundle attachment

Daito GA260W NC saw with bundle attachment

NSK Indexer adaptable to all machining centers

NSK Indexer adaptable to all machining centers

Computer Aided Design (CAD) and Machining Packages

AutoCAD Version 12

AutoCAD Version 12

Surfcam 3D Milling and Turning Package

Surfcam 3D Milling and Turning Package

Latest revisions

Partmaker CAD/CAM System

Partmaker CAD/CAM System

Swissturn Package
Turn Package
Mill/Turn Package
Milling Package
EDM Wire Package
(Latest Revisions)
